LED TRAFFIC VMS Lighting the Future
| Model | horizontal | vertical |
|---|---|---|
| Pixel Pitch | 4 mm | |
| Display Area | (W) 1280 x (H) 192 mm | (W) 192 x (H) 1280 mm |
| Viewing Angle | horizontal: 120˚ | |
| Resolution | (W) 320 dots x (H) 48 dots | (W) 48 dots x (H) 320 dots |
| Brightness | 5,000 nits | |
| Color | Full Color Based on Red\Green\Blue | |
| Character Font | Chinese 16*16, English 16*16 | |
| Brightness Adjustment | 15 level adjustable | |
| Frame Refresh Rate | ≥ 60 Hz | |
| IP Level | Front IP65, Rear IP43 | |
| Operation Power Voltage | 110 / 220 VAC ±10 %, 50 or 60 Hz | |
| Power Consumption | 320W.(AVE)100 | |
| Operation Environment | -10~+50 ℃ | |
| EMC/EMI | ||
| Model | |
|---|---|
| Operating Voltage | 100~240 VAC |
| Display Area | 256 x 256 mm |
| Color | Full Color Based on Red\Green\Blue |
| Pixel Pitch | 4 mm |
| Resolution | 64 dots x 64 dots |
| Brightness | > 4,000 nits (white balance) |
| IP Level | IP54 |
| Display | Text, image and animation |
| Data Transmission | WIFI |
| Play Mode | According to the red/green pedestrian signal |
| Brightness | Can be set by the schedule |
| Model | Three lines |
|---|---|
| Pixel Pitch | 4 mm |
| Display Area | (W) 1280 x (H) 576 mm |
| Viewing Angle | horizontal: 120˚ |
| Resolution | (W) 320 dots x (H) 144 dots |
| Brightness | 5,000 nits |
| Color | Full Color Based on Red\Green\Blue |
| Character Font | Chinese 16*16, English 16*16 |
| Brightness Adjustment | 15 level adjustable |
| Frame Refresh Rate | ≥ 60 Hz |
| IP Level | Front IP65, Rear IP43 |
| Operation Power Voltage | 110 / 220 VAC ±10 %, 50 or 60 Hz |
| Power Consumption | 960W.(AVE)300 |
| Operation Environment | -10~+50 ℃ |
| EMC/EMI |
